Summary：

      Automation in packaging industry is now changing the packaging process and the processing methods for packaging containers and materials. The automatic control of the packaging system can greatly improve the production efficiency and product quality, besides it can also greatly eliminate the error caused by the packaging process and the print of label, and effectively reduce the working intensity of workers and the consumption of energy and resources.

Working Principle of Automatic Packing:

        Put the material into weighing hopper through the feed gear (pneumatic gate), the controller receives the weight signal from the sensor, then control the system through a per-set program. At the beginning, feed the material very quickly, when the weight≥ target value (coarse measurement value), change the signal, feed the material in the medium speed, when the weight≥ target value (precision measurement value), change the signal, feed the material in the slow speed, when the weight≥ target value ( overshoot value), stop the signal, the pneumatic gate is closed. After input the clip bag signal, the weighing hopper discharge doors will automatically open. When the weight ≤ zero settings, the weighing hopper discharge doors will automatically close, the material bag fall into the conveyor belt, sending to the sewing machine, at the same time, the controller enters the next control cycle.

Composition of Automatic Packaging System:

Material entrance, feeding mechanism (gate), weigh hopper, the folder bag system, rack, suction outlet, pneumatic systems, sensors, control box, transport and joint package system.

Applications of Automatic Packing:

Particulate material of food, feed, seed, building materials, fertilizers and so on.

Features of Automatic Packaging System:

1. The overall mobile system, convenient, stable and reliable.

2. The material contact parts are made of stainless steel with corrosion resistance and high hygiene standards.

3. The unique feeder design, double cylinder drive and adjustable feed gate, adapts to different material and ensure the precision requirements.\

4. Direct bagging weighing, suitable for light weight, large weight fast measurement and packaging.

5. 20 different kind of packaging weight measurement, to meet the requirements of variety of weighing and packing.

6. Choose the high quality of import and domestic electrical devices and pneumatic components configuration to ensure the stable operation of equipment.

Technical parameters:

Note:

1) Packing accuracy and speed depend on the characteristics of material.

2) Power consumption (approximately) 1.1kw / h

3) Power AC380V/50HZ / ± 10%

4) Air source (compressed air) 0.5 MPA
