Product introduction
MF- II square pulse bag filter is modified and modified on the basis of MF- type I.
Performance characteristics
In addition to its characteristics such as high dust removal efficiency, large amount of air handling, stable performance, convenient operation and maintenance, it also has the advantages of better use effect, less powder accumulation and wide application range than the I type.
Adaptive material
Widely used in food, food, feed, metallurgy, chemical, building materials, pharmaceuticals and other industries of ventilation, dust collection and dust recovery.
Technical specifications
|
Parameter |
Model |
||||||
|
MF48 |
MF60 |
MF72 |
MF84 |
MF96 |
MF108 |
MF120 |
|
|
Filtration area（m2） |
36.2 |
45.2 |
54.3 |
63.3 |
72.4 |
81.4 |
90.5 |
|
Number of filter bags |
48 |
60 |
72 |
84 |
96 |
108 |
120 |
|
Filtration rate (m3/h) |
6510-8680 |
8130-10840 |
9770-13000 |
11400-1520 |
13000-17370 |
14650-19530 |
16290-21700 |
|
Solenoid valve quantity（只） |
8 |
10 |
12 |
14 |
16 |
18 |
20 |
|
Power (kw) |
1.1 |
1.1 |
1.1 |
1.1 |
1.5 |
2.2 |
2.2 |
|
Filter bag specification (mm) |
120×2000 |
||||||
|
Filtration velocity (m/min) |
3-4 |
||||||
|
leak out rate (%) |
≤5 |
||||||
|
Injection pressure (Mpa) |
＞0.4-0.6 |
||||||
|
Equipment resistance (Pa) |
＜1200 |
||||||
|
Dust removal efficiency (%) |
≥99.9（Select the suitable filter material according to the dust characteristics ） |
||||||
Technical specifications
|
Parameter |
Model |
||||||
|
MF48 |
MF60 |
MF72 |
MF84 |
MF96 |
MF108 |
MF120 |
|
|
A |
3530 |
3530 |
3530 |
3530 |
3530 |
3530 |
3530 |
|
B |
3287 |
3287 |
3287 |
3287 |
3287 |
3287 |
3287 |
|
C |
2552 |
2552 |
2552 |
2552 |
2552 |
2552 |
2552 |
|
D |
1160 |
2260 |
1160 |
1160 |
1160 |
1160 |
1160 |
|
E |
1350 |
1650 |
1950 |
2250 |
1350 |
2850 |
3150 |
|
F |
1350 |
1350 |
1350 |
1350 |
1350 |
1350 |
1350 |
|
G |
635 |
635 |
635 |
635 |
635 |
635 |
635 |
|
H |
325 |
475 |
625 |
775 |
925 |
1075 |
1225 |
|
I |
1586 |
1586 |
1586 |
1586 |
1586 |
1586 |
1586 |
|
J |
790 |
790 |
790 |
790 |
850 |
850 |
850 |
|
K |
824 |
824 |
824 |
824 |
824 |
824 |
824 |
|
M×N |
400×500 |
500×500 |
600×500 |
700×600 |
700×600 |
800×600 |
800×600 |
|
P×Q |
432×530 |
530×530 |
630×530 |
728×630 |
728×630 |
832×630 |
832×630 |
|
R×S |
1050×1050 |
1350×1050 |
1650×1050 |
1950×1050 |
2250×1050 |
2250×1050 |
2850×1050 |
