        Name: HZS series rotary screen

        Keywords: HZS series rotary screen
        Description: Product overview:  HZS Series Rotary Screen mainly consists of motor, reducer, drum units, racks,etc. Inclination of drum equipment, motor is connected by reducer & the drum unit, the drive drum rotate around its axis. When the materials …

        Details

        Product overview:

              HZS Series Rotary Screen mainly consists of motor, reducer, drum units, racks,etc. Inclination of drum equipment, motor is connected by reducer & the drum unit, the drive drum rotate around its axis. When the materials go into the drum unit, due to the inclination and the rotation of drum unit, it makes qualified materials come out by the outer screen, substandard materials come out by the end of rotary screen.

              This series of rotary screen work fine, durable frame with steel welding, large funnel volume , welded steel plate. Drum unit is sealed by the cover of body, to ensure equipment in the work process, prevent dust escape and eliminate dust pollution. When replace screen, simply open the lid of the body to change, easy to operate

        The main technical parameters of HZS Series Rotary Screen:



        Model

        HZS-1.0

        HZS-1.2

        HZS-1.5

        HZS-1.8

        HZS-2.0

        HZS-2.2

        Drum diameter (mm)

        1000

        1200

        1500

        1800

        2000

        2200

        Drum length (mm)

        3500

        3500

        4000

        7000

        6000

        8000

        Obliguity(°)

        4

        4

        4

        4

        4

        4

        Speedr/min

        17

        17

        17

        15

        15

        15

        Motor power(kw)

        4

        4

        5.5

        18.5

        18.5

        22
